Aluminum Tread Plate

» Aluminum Tread Plate

    • 1000 Series Aluminum Tread Plate

    CATEGORY AND TAGS:
    Aluminum Tread Plate

    Grade: 1000 Series

    Temper: O-H112

    Type: Plate

    Application: Construction

    Thickness: 0.85-6.35mm

    Width: 600-2200mm

    Surface Treatment: Embossed

    enquiry
    • Specifications

    Grade: 1000 Series                                                   Temper: O-H112

    Type: Plate                                                                    Application: Construction

    Thickness: 0.85-6.35mm                                        Width: 600-2200mm

    Surface Treatment: Embossed                               Alloy Or Not: Non-alloy

    Model Number: 1000 series                                  Payment terms: L/C , TT

    MOQ: 8 ton                                                                   Surface: embossed

    Color: Silver                                                                  Shape: sheet plate and coil

    Certification: ISO9001 SGS MSDS ROHS

    Alloy: 1050, 1060, 1100

    Chemical composition%
    Grade Si Fe Cu Mn Mg Cr Ni Zn Al
    1050 0.250 0.400 0.050 0.050 0.050 – – 0.050 99.50
    1060 0.250 0.350 0.050 0.030 0.030 – – 0.050 99.60
    1070 0.200 0.250 0.040 0.030 0.030 – – 0.040 99.70





    Mechanical Properties


    Alloy

    		 Anti-tensile strength

    N/m2

    		 Stretch rate(%)

    Dimension Control



    surface
    1050 75 37 Qualified Qualified
    1060 75 35 Qualified Qualified
    1070 80 25 Qualified Qualified
    1100 90 35 Qualified Qualified
    1200 80 30 Qualified Qualified
